J-BOX BAFFLE LED DOWNLIGHT
 |
FEATURES
Spun aluminum with regressed baffle trim for free glares4 Inch 10W ;6 Inch 15W The adjustable CCT variant allows 2700K, 3000K, 3500K, 4000K, and 5000K color temperatures adjustment. 120V Power supply with Triac dimmable performance CRI rating over 90. Beam angle spans 100°. Dimming range between 5% and 100%. Remodel and New construction applications
|
| Item No. | Mounting | Voltage | Wattage | CRI | Color Temp | Optics | Driver | Options | Size (mm) | Cutout (mm) | Trim Finish |
| LBT-4CBES- | Remodel；
New Construction | 120Vac 100-277Vac 100-347Vac 220-240Vac | 10W | 80Ra+
90Ra+ | 3CCT 5CCT DTW 2700K-6500K | 110° | Triac Dim. 0-10V Dim. Dali Dim. On/Off only | Standard
EM Backup | 140x75
| 110 | White Black Silver Brush Nickel |
| LBT-6CBES- | 15W | 118x75 | 150 |
| LBT-4CBES-XX | 10+3W | 140x75 | 110 |
| LBT-6CBES-XX | 15+4W | 118x75 | 150 |
